Table 5-3. CPU Clock Transition and SFR Register Setting Examples for 16-Pin and 20-Pin Products (2/2)
(2) CPU clock changing from high-speed system clock (B) to high-speed on-chip oscillator clock (A)
(Setting sequence of SFR registers)
Setting Flag of SFR Register
Status Transition
CSC Register Oscillation accuracy stabilization time CKC Register
HIOSTOP MCM0
(B) → (A) 0 27 µs (typ.) 0
Unnecessary if the CPU is operating with the high-speed
on-chip oscillator clock
(3) HALT mode (C) set while CPU is operating with high-speed on-chip oscillator clock (A)
HALT mode (D) set while CPU is operating with high-speed system clock (B)
Status Transition Setting
(A) → (C)
(B) → (D)
Executing HALT instruction
(4) STOP mode (E) set while CPU is operating with high-speed on-chip oscillator clock (A)
STOP mode (F) set while CPU is operating with high-speed system clock (B)
(Setting sequence of SFR registers)
Status Transition Setting
(A) → (E)
Stopping peripheral
functions that cannot
operate in STOP
mode
—
Executing STOP
instruction
(B)→ (F) In X1 oscillation Sets the OSTS register
External clock —
Remark (A) to (F) in Table 5-3 correspond to (A) to (F) in Figure 5-14.
