RL78/G15 CHAPTER 6 TIMER ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 234 of 765

Mar 7, 2023

Figure 6-45. Example of Basic Timing of Operation as External Event Counter

TSmn

TEmn

TDRmn

TCRmn

INTTMmn

0003H

4 events

0002H

0000H

4 events

3 events

TImn

Remark 1. m: Unit number (m = 0), n: Channel number (n = 0 to 7)

Remark 2. TSmn: Bit n of timer channel start register m (TSm)

TEmn: Bit n of timer channel enable status register m (TEm)

TImn: TImn pin input signal

TCRmn: Timer count register mn (TCRmn)

TDRmn: Timer data register mn (TDRmn)
