RL78/G15 CHAPTER 6 TIMER ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 256 of 765

Mar 7, 2023

Figure 6-61. Example of Basic Timing of Operation as Delay Counter

TSmn

TEmn

TDRmn

TCRmn

INTTMmn

a + 1

b + 1

TImn

0000H

FFFFH

Remark 1. m: Unit number (m = 0), n: Channel number (n = 0 to 7)

Remark 2. TSmn: Bit n of timer channel start register m (TSm)

TEmn: Bit n of timer channel enable status register m (TEm)

TImn: TImn pin input signal

TCRmn: Timer count register mn (TCRmn)

TDRmn: Timer data register mn (TDRmn)
