RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 269 of 765
Mar 7, 2023
Figure 6-68. Operation Procedure of One-Shot Pulse Output Function (3/3)
Software Operation Hardware Status
TAU stop To hold the TOmp pin output level
Clears the TOmp bit to 0 after the value to be held
is set to the port register.
When holding the TOmp pin output level is not
necessary
Setting not required.
The TOmp pin output level is held by port function.
The TAUmEN bit of the PER0 register is cleared
to 0.
Power-off status
All circuits are initialized and SFR of each channel
is also initialized.
(The TOmp bit is cleared to 0 and the TOmp pin is
set to port mode)
Remark m: Unit number (m = 0), n: Master channel number (n = 0, 2, 4, 6)
p: Slave channel number (n < p ≤ 7)
