RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 283 of 765
Mar 7, 2023
Figure 6-76. Example of Set Contents of Registers When Multiple PWM Output Function (Master Channel) Is Used (1/2)
(a) Timer mode register mn (TMRmn)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TMRmn
CKSm
n1
CKSm
n0
CCSm
n
MAST
ERmn
Note 1
2
1
0
CISmn
1
CISmn
0
MDmn
3
MDmn
2
MDmn
1
MDmn
0
1/0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 1
Operation mode of channel n
000B: Interval timer
Setting of operation when
counting is started
1: Generates INTTMmn
when counting is started.
Selection of TImn pin input edge
00B: Sets 00B because these are not used.
Start trigger selection
000B: Selects only software start.
Setting of MASTERmn bit (channels 2, 4, 6)
1: Master channel.
Count clock selection
0: Selects operation clock (f
MCK
).
Operation clock (f
MCK
) selection
00B: Selects CKm0 as operation clock of channel n.
10B: Selects CKm1 as operation clock of channel n.
Note 1. TMRm2, TMRm4, TMRm6: MASTERmn = 1
TMRm0: Fixed to 0
Remark m: Unit number (m = 0), n: Master channel number (n = 0, 2, 4)
