RL78/G15 CHAPTER 10 A/D CONVERTER

R01UH0959EJ0110 Rev.1.10 Page 332 of 765

Mar 7, 2023

Figure 10-11. Conversion Operation of A/D Converter (Software Trigger Mode)

Writing 1 to ADCS

ADCS

Sampling time

A/D converter

operation

Conversion

standby

Sampling

D conversion

Conversion

standby

Conversion time

Undefined

SAR

ADCR, ADCRH

INTAD

Conversion

result

Conversion

result

A/D conversion is performed once when the bit 7 (ADCS) of A/D converter mode register 0 (ADM0) is set to 1 by

software. The ADCS bit is automatically cleared to 0 after A/D conversion ends.

Reset signal generation clears the A/D conversion result register (ADCR, ADCRH) to 0000H or 00H.
