RL78/G15 CHAPTER 1 OUTLINE
R01UH0959EJ0110 Rev.1.10 Page 37 of 765
Mar 7, 2023
(2/2)
Item 8-pin 10-pin 16-pin 20-pin
R5F12007 R5F12008 R5F12017 R5F12018 R5F12047 R5F12048 R5F12067 R5F12068
On-chip debug function Provided
Power supply voltage V
DD
= 2.4 to 5.5 V
Operating ambient temperature T
A
= −40 to +85°C (A: Consumer applications), T
A
= −40 to +105°C (G: Industrial applications), T
A
= −40 to +125°C
(M: Industrial applications)
Note 1. The number of outputs varies, depending on the setting of channels in use and the number of the master (see
6.9.3 Operation as multiple PWM output function).
Note 2. Although the CSI function is generally called SPI, it is also called CSI in this product, so it is referred to as
such in this manual.
Note 3. The illegal instruction is generated when instruction code FFH is executed. Reset by the illegal instruction
execution not issued by emulation with the on-chip debug emulator.
