Figure 12-16. Examples of Reverse Transmit Data

(a) Non-reverse Output (SOLmn = 0)

SOLmn = 0 output

TxDq

ST P S

Transmit data

(b) Reverse Output (SOLmn = 1)

SOLmn = 1 output

TxDq

ST P S

Transmit data (inverted)

Remark m: Unit number (m = 0), n: Channel number (n = 0)
