RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 396 of 765

Mar 7, 2023

Figure 12-20. Each Register Setting When Stopping the Operation by Channels (2/2)

(d) Serial output register m (SOm) … The SOm is a buffer register for serial output of each channel.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

SOm

CKOm

SOm1

SOm0

0 0 0 0 0 0 0/1 0/1 0 0 0 0 0 0 0/1 0/1

1: Serial clock output value is 1

1: Serial data output value is 1

*When using pins corresponding to each channel as port function pins, set the corresponding CKOmn, SOmn bits to 1.

Remark 1. m: Unit number (m = 0), n: Channel number (n = 0, 1)

Remark 2.

: Setting disabled (set to the initial value), 0/1: Set to 0 or 1 depending on the usage of the user.
