RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 413 of 765

Mar 7, 2023

(3) Processing flow (in single-reception mode)

Figure 12-33. Timing Chart of Master Reception (in Single-Reception Mode) (Type 1: DAPmn = 0, CKPmn = 0)

Shift

Slp

SCKp

Data receptionData reception

Data reception

SSmn

STmn

SEmn

SDRmn

INTCSIp

TSFmn

Dummy data for reception

Dummy data

Receive data 1

Receive data

Receive data 3

Reception

shift operation

Reception

shift operation

Reception

& shift operation

Write

Read

Receive data

Remark m: Unit number (m = 0), n: Channel number (n = 0, 1), p: CSI number (p = 00, 01), mn = 00, 01
