RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 420 of 765

Mar 7, 2023

Figure 12-37. Example of Contents of Registers for Master Transmission/Reception of simplified SPI (CSI00, CSI01)

(2/2)

(e) Serial output enable register m (SOEm) … Set only the bit of the target channel to 1.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

SOEm

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0/1 0/1

(f) Serial channel start register m (SSm) … Set only the bit of the target channel to 1.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

SSm

SSm1

SSm0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0/1 0/1

Remark 1. m: Unit number (m = 0), n: Channel number (n = 0, 1), p: CSI number (p = 00, 01), mn = 00, 01

Remark 2.

: Setting is fixed in the simplified SPI (CSI) master transmission/reception mode,

: Setting disabled (set to the initial value)

0/1: Set to 0 or 1 depending on the usage of the user.
