RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 433 of 765

Mar 7, 2023

(3) Processing flow (in single-transmission mode)

Figure 12-49. Timing Chart of Slave Transmission (in Single-Transmission Mode) (Type 1: DAPmn = 0, CKPmn = 0)

Shift

SOp pin

SCKp pin

Data transmissionData transmissionData transmission

SSmn

STmn

SEmn

SDRmn

INTCSIp

TSFmn

Transmit data 1

Transmit data 2

Transmit data 3

Transmit data 1 Transmit data 2

Transmit data

Shift operation

Remark m: Unit number (m = 0), n: Channel number (n = 0, 1), p: CSI number (p = 00, 01), mn = 00, 01
