RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 484 of 765

Mar 7, 2023

The channel supporting simplified I

C (IIC00, IIC01) is channels 0 and 1 of SAU0.

 10- and 8-pin products

Unit Channel Used as simplified SPI (CSI) Used as UART Used as Simplified I

0 0 CSI00 UART0 IIC00

1 — —

 20- and 16-pin products

Unit Channel Used as simplified SPI (CSI) Used as UART Used as Simplified I

0 0 CSI00 UART0 IIC00

1 CSI01 IIC01

Simplified I

C (IIC00, IIC01) performs the following four types of communication operations.

●

Address field transmission (See 12.7.1.)

●

Data transmission (See 12.7.2.)

●

Data reception (See 12.7.3.)

●

Stop condition generation (See 12.7.4.)
