RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 487 of 765

Mar 7, 2023

Figure 12-85. Example of Contents of Registers for Address Field Transmission of Simplified I

C (IIC00, IIC01) (2/2)

(f) Serial channel start register m (SSm) … Set only the bit of the target channel to 1.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

SSm

SSm1

SSm0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0/1 0/1

SSmn = 0 until the start condition is generated, and SSmn = 1 after generation.

Note 1. The SMR00 register only.

Note 2. The SCR00 register only.

Remark 1. m: Unit number (m = 0), n: Channel number (n = 0, 1), r: IIC number (r = 00, 01), mn = 00, 01

Remark 2.

: Setting is fixed in the IIC mode, : Setting disabled (set to the initial value)

0/1: Set to 0 or 1 depending on the usage of the user.
