RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 489 of 765

Mar 7, 2023

(3) Processing flow

Figure 12-87. Timing Chart of Address Field Transmission

Shift

SCLr output

SSmn

SEmn

SOEmn

SDRmn

INTIICr

TSFmn

Address field transmission

Shift operation

SDAr input

D6 D5 D4 D3 D2 D1 D0 ACK

SDAr output

D6 D5 D4 D3 D2 D1 D0

Address

R/W

SOmn bit manipulation

CKOm bit manipulation

Remark m: Unit number (m = 0), n: Channel number (n = 0, 1), r: IIC number (r = 00, 01), mn = 00, 01
