RL78/G15
CHAPTER 2
PIN
FUNCTIONS
R01UH0959EJ011
0
Rev.1
.10
Page
53
of
765
Mar 7, 2023
Figure
2-8.
Pin Block
Diagra
m for Pin Type
7-9-1
Output latch
(Pmn)
WR
PU
Alternate function
Alternate function
(SAU)
Alternate function
(other than SAU)
PU register
(PUmn)
Pmn
P-ch
P-ch
N-ch
V
DD
V
DD
V
SS
1
0
RD
PORT
WR
PORT
PM register
(PMmn)
WR
PM
WR
PMC
PMC register
(PMCmn)
P-ch
N-ch
A/D converter
Comparator input
Internal bus
Remark 1.
For alternate f
unctions, see
2.1
Port Function
.
Remark 2.
SAU: Serial arr
ay unit
52
54
