RL78/G15 CHAPTER 13 SERIAL INTERFACE IICA

R01UH0959EJ0110 Rev.1.10 Page 578 of 765

Mar 7, 2023

(6) Arbitration loss operation (not participating in communications after arbitration loss)

When the device is used as a master in the multi-master system, read the MSTS0 bit to check the arbitration result each

time interrupt request signal INTIICA0 is generated.

(a) When lost in arbitration during transmission of slave address data (when WTIM0 = 1)

ST AD6-AD0 R/W D7-D0 SPACK ACKACK D7-D0

1: IICS0 = 01000110B

2: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

(b) When lost in arbitration during transmission of extension code

AD6-AD0

R/W

D7-D0

ACK

D7-D0

1: IICS0 = 0110×010B

Sets LREL0 = 1 by software

2: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care
