RL78/G15 CHAPTER 13 SERIAL INTERFACE IICA

R01UH0959EJ0110 Rev.1.10 Page 577 of 765

Mar 7, 2023

(b) When lost in arbitration during transmission of extension code

(i) When WTIM0 = 0

AD6-AD0

R/W

-D

ACK

D7-D0

1: IICS0 = 0110×010B

2: IICS0 = 0010×000B

3: IICS0 = 0010×000B

4: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care

(ii) When WTIM0 = 1

2 3

AD6-AD0

R/W

D7-D0

ACK

D7-D0

1: IICS0 = 0110×010B

2: IICS0 = 0010×110B

3: IICS0 = 0010×100B

4: IICS0 = 0010××00B

5: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care
