Renesas RL78/G15 User Manual

RL78/G15 CHAPTER 14 INTERRUPT FUNCTIONS
R01UH0959EJ0110 Rev.1.10 Page 611 of 765
Mar 7, 2023
Address: FFFEEH After reset: FFH R/W
Symbol
□
7
□
6
□
5
□
4
□
3
□
2
□
1
□
0
PR11L TMPR106 TMPR105 TMPR104 ITPR1 TMPR103 TMPR102 IICAPR10 TMPR103H
Address: FFFEBH After reset: FFH R/W
Symbol 7 6 5 4 3
□
2
□
1
□
0
PR01H 1 1 1 1 1 CMPPR01 CMPPR00 TMPR007
Address: FFFEFH After reset: FFH R/W
Symbol 7 6 5 4 3
□
2
□
1
□
0
PR11H 1 1 1 1 1 CMPPR11 CMPPR10 TMPR107
XXPR1X XXPR0X Priority level selection
0 0 Specify level 0 (high priority level)
0 1 Specify level 1
1 0 Specify level 2
1 1 Specify level 3 (low priority level)
Caution The available registers and bits differ depending on the product. For details about the registers and
bits available for each product, see Table 14-2. Be sure to set bits that are not available to the initial
value.
