RL78/G15 CHAPTER 20 ON-CHIP DEBUG FUNCTION

R01UH0959EJ0110 Rev.1.10 Page 684 of 765

Mar 7, 2023

For the target system which uses the multi-use feature of RESET

¯¯¯¯¯¯

pin, its connection to an external circuit should be

isolated.

Figure 20-2. Connection Example of E2, E2 Lite On-chip Debugging Emulator and RL78 microcontroller

(When using to the alternative function of RESET

¯¯¯¯¯¯

pin)

TOOL0

External circuit

TOOL0

EMV

E2, E2 Lite

target connector

Output pin

GND

Reset_out

______

RESET

Reset_out

Reset_in

1 kΩ

RL78/G15

RSTPU
