RL78/G15 CHAPTER 24 ELECTRICAL SPECIFICATIONS (T

A

= −40 to +105°C, TA = −40 to +125°C)

R01UH0959EJ0110 Rev.1.10 Page 740 of 765

Mar 7, 2023

TI/TO Timing

t

TIL

t

TIH

1/f

TO

TI00 to TI07

TO00 to TO07

RESET

¯¯¯¯¯¯

Input Timing

t

RSL

______

RESET
