11.2 Quick Start Parameters
Code Name Setting range Default Min. Attri.
C0.05 Carrier frequency DOM DOM 1 Run
C1.05 Motor rated power 0.1...1,000.0 kW DOM 0.1 Stop
C1.06 Motor rated voltage 0...480 V DOM 1 Stop
C1.07 Motor rated current 0.01...655.00 A DOM 0.01 Stop
C1.08 Motor rated frequency 5.00...400.00 Hz 50.00 0.01 Stop
C1.09 Motor rated speed 1...30,000 rpm DOM 1 Stop
C2.00 V/f curve mode
0: Linear
1: Square
2: User-defined
0 – Stop
E0.00 First frequency setting source 0...99 0 – Stop
E0.01 First run command source 0...2 0 – Stop
E0.07 Digital setting frequency 0.00...[E0.09] Hz 50.00 0.01 Run
E0.08 Maximum output frequency 50.00...400.00 Hz 50.00 0.01 Stop
E0.09 Output frequency high limit [E0.10]...[E0.08] Hz 50.00 0.01 Run
E0.10 Output frequency low limit 0.00...[E0.09] Hz 0.00 0.01 Run
E0.17 Direction control
0: Forward / Reverse
1: Forward only
2: Reverse only
3: Swap default direction
0 – Stop
E0.25
Acceleration / deceleration
curve mode
0: Linear mode
1: S-curve
0 – Stop
E0.26 Acceleration time 0.1...6,000.0 s DOM 0.1 Run
E0.27 Deceleration time 0.1...6,000.0 s DOM 0.1 Run
E0.35 Start mode
0: Start directly
1: DC-braking before start
2: Start with speed capture
3: Automatic start / stop ac-
cording to setting frequency
0 – Stop
E0.50 Stop mode
0: Decelerating stop
1: Freewheeling stop
2: Freewheeling with stop
command, decelerating with
direction change
0 – Stop
Tab. 11-4: Quick start parameters
Bosch Rexroth AG
Quick Start
EFC x610 Series
94/389
DOK-RCON03-EFC-X610***-IT05-EN-P
