C2: V/f control parameters
Code Name Setting range Default Min. Attri.
C2.00 V/f curve mode
0: Linear
1: Square
2: User-defined
0 – Stop
C2.01 V/f frequency 1 0.00...[C2.03] Hz 0.00 0.01 Stop
C2.02
V/f voltage 1
①
0.0...120.0 % 0.0 0.1 Stop
C2.03 V/f frequency 2 [C2.01]...[C2.05] Hz 0.00 0.01 Stop
C2.04
V/f voltage 2
①
0.0...120.0 % 0.0 0.1 Stop
C2.05 V/f frequency 3 [C2.03]...[E0.08] Hz 50.00 0.01 Stop
C2.06
V/f voltage 3
①
0.0...120.0 % 100.0 0.1 Stop
C2.07 Slip compensation factor 0…200 % 0 1 Run
C2.21 Torque boost setting
0.0 %: Automatic boost
0.1...20.0 %: Manual boost
0.0 0.1 Run
C2.22 Automatic torque boost factor 0...320 % 50 1 Run
C2.23
Heavy load stabilization
setting
0: Inactive
1: Active
1 – Run
C2.24
Light load oscillation damping
factor
0...5,000 % 0 1 Run
C2.25
Light load oscillation damping
filter factor
10...2,000 % 100 1 Run
C2.40 Current limitation mode
0: Always inactive
1: Inactive at constant speed
2: Active at constant speed
2 – Stop
C2.42
Current limitation level
②
[C0.27]...250 % 150 1 Stop
C2.43
Current limitation
proportional gain
0.000...10.000 DOM 0.001 Stop
C2.44
Current limitation
integral time
0.001...10.000 DOM 0.001 Stop
①
: percentage of motor rated voltage [C1.06].
②
: percentage of frequency converter rated current.
EFC x610 Series
Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-X610***-IT05-EN-P
337/389
