11 Quick Start
11.1 Checklist before Quick Start
11.1.1 Step 1: Check application conditions
Rated ambient temperature -10...45 ℃
Derating / ambient temperature 1.5 % / 1 °C (45...55 °C)
Rated storage temperature -20...60 ℃
Rated altitude ≤ 1,000 m
Derating / altitude 1 % / 100 m (1,000...4,000 m)
Mounting mode (Wall mounting) Wall mounting, DIN rail mounting
Tab. 11-1: Application conditions checklist
See also in chapter 6.1.9 "Conditions" on page 22.
11.1.2 Step 2: Check mounting conditions
Converter mounting direction Vertical
Minimum top space
d
top
= 125 mm
Minimum bottom space
d
bot
= 125 mm
One converter is arranged above another Air guide available is required in between
Mounting screws 4 x M6, no loose screws
Tab. 11-2: Mounting conditions checklist
See also in chapter 7.1 "Installation Conditions" on page 31.
11.1.3 Step 3: Check the wiring
Mains connection Connect L1, L2, (L3) of converter to mains accordingly
Motor connection Connect U, V, W of converter to motor accordingly
Grounding Must be securely connected
Shielding Must be securely connected
Power cables Must observe chapter 8.2.1 "Power Cables" on page 42
Control terminals connection Must be securely connected
Control cables Must observe chapter 8.2.2 "Control Cables" on page 47
EMC
Must observe chapter 9 "Electromagnetic Compatibility
(EMC)" on page 63
Switches Must be switched off
Load Must be disconnected
Tab. 11-3: Wiring checklist
EFC x610 Series Bosch Rexroth AG
Quick Start
DOK-RCON03-EFC-X610***-IT05-EN-P
93/389
