REXROTH EFC 3610 Series User Manual

8.2 Cable Specifications
8.2.1 Power Cables
Cable specification for international without USA / Canada
● ONLY USE copper wires of 90 ℃ or above with XLPE or EPR insu-
lation according to IEC60364-5-52.
● It is recommended to use shielded cables to connect the motor.
● *: If additional labels available with the terminals of 0K40...7K50,
please refer to the torque data on labels.
EFC x610
Model
Fuse (gG)
Power cables installation mode
PE Cable Torque / Screw
B1 B2 E
[A]
[mm
2
] [mm
2
] [mm
2
] [mm
2
]
[N·m / lb·in] (Mx)
0K40 10.0 2.5 2.5 2.5 10.0 1.00* / 9.0 (M3)
0K75 16.0 2.5 2.5 2.5 10.0 1.00* / 9.0 (M3)
1K50 25.0 4.0 4.0 2.5 10.0 1.00* / 9.0 (M3)
2K20 32.0
6.0
①
6.0
①
4.0 10.0 1.00* / 9.0 (M3)
Tab. 8-1: 1P 200 VAC fuse and cable dimensions for international without USA / Canada
①
: Stranded with ferrule without plastic sleeve.
EFC x610
Model
Fuse (gG)
Power cables installation mode
PE Cable Torque / Screw
B1 B2 E
[A]
[mm
2
] [mm
2
] [mm
2
] [mm
2
]
[N·m / lb·in] (Mx)
0K40 6.0 2.5 2.5 2.5 10.0 1.00* / 9.0 (M3)
0K75 10.0 2.5 2.5 2.5 10.0 1.00* / 9.0 (M3)
1K50 10.0 2.5 2.5 2.5 10.0 1.00* / 9.0 (M3)
2K20 16.0 2.5 2.5 2.5 10.0 1.00* / 9.0 (M3)
3K00 20.0 4.0 4.0 2.5 10.0 1.00* / 9.0 (M3)
4K00 20.0 4.0 4.0 2.5 10.0 1.00* / 9.0 (M3)
5K50 32.0 6.0 6.0 4.0 10.0 1.20* / 10.5 (M4)
7K50 40.0 6.0 10.0 6.0 10.0 1.20* / 10.5 (M4)
11K0 50.0 10.0 10.0 10.0 10.0 1.76 / 15.6 (M4)
15K0 50.0 10.0 10.0 10.0 10.0 1.76 / 15.6 (M4)
18K5 80.0 25.0 25.0 16.0 16.0 3.73 / 33.0 (M5)
22K0 100.0 25.0 35.0 25.0 25.0 3.73 / 33.0 (M5)
Bosch Rexroth AG
Frequency Converter Wiring
EFC x610 Series
42/389
DOK-RCON03-EFC-X610***-IT05-EN-P
