REXROTH EFC 3610 Series User Manual

6 Frequency Converter Overview
6.1 Product Features
6.1.1 Input
Power supply voltage
1P 200...240 VAC (-10 % / +10 %) (IT-Net, TN-Net)
3P 380...480 VAC (-15 % / +10 %) (IT-Net, TN-Net)
Power supply frequency 50 / 60 Hz (±5 %)
6.1.2 Output
Rated voltage Corresponding to input voltage
Rated power
0.4...2.2 kW (1P 200 VAC)
0.4...90 kW (3P 400 VAC)
Rated frequency 0.00...400.00 Hz
Default carrier frequency 4 kHz
Carrier frequency range
0.4...22 kW: 1...15 kHz
30...90 kW: 1...12 kHz
Efficiency > 95 %
Overload capability
HD: 200 % of rated current for 1 s
HD: 150 % of rated current for 60 s
ND: 120 % of rated current for 60 s
dv / dt (Without filter) < 5kV / us
6.1.3 V/f Control Performance
V/f curve Linear mode, square curve mode, user-defined multi-point curve mode
Speed regulation range 1:50
Start-up torque
150 % of rated torque at 3.00 Hz
100 % of rated torque at 1.50 Hz
6.1.4 SVC Control Performance
Speed regulation range 1:200
Start-up torque 200 % of rated torque at 0.50 Hz
EFC x610 Series Bosch Rexroth AG
Frequency Converter Overview
DOK-RCON03-EFC-X610***-IT05-EN-P
19/389
