REXROTH EFC 3610 Series User Manual

Fault status register (0x7FB0)
The fault status of frequency converter can be monitored by reading the regis-
ter.This register is read-only. The definition of each bit is shown in the table be-
low:
bit Value Description Errors
15
1 Miscellaneous
ESS-, UH, Pdr, t-Er, AdE-, AibE,
EPS-, dir1, dir2, FFE-, E.Par, PbrE,
APP-, APE1, APE2, APE3, APE4,
APE5, etc.
0 OK
14...10 Reserved
9
1 Internal fault idE-, idP-, idA-, OCd-
0 OK
8
1 Communication fault rS-, Fdi-, OCc
0 OK
7
1 External fault E-St
0 OK
6
1 Fan fault FF
0 OK
5
1 Under voltage UE-1
0 OK
4
1 Phase loss IPH.L, OPH.L
0 OK
3
1 Overheat OH, Ot
0 OK
2
1 Overload OL-1, OL-2
0 OK
1
1 Over voltage OE-1, OE-2, OE-3, OE-4
0 OK
0
1 Over current OC-1, OC-2, OC-3, SC
0 OK
Tab. 14-27: Fault status register (0x7FB0)
Communication frequency setting register (0x7F01)
The address of frequency setting register for communication control is 0x7F01.
This register is for read and write. When 'First frequency setting source' [E0.00]
= '20: Communication', the frequency converter can be set with writing data to
this address.
EFC x610 Series
Bosch Rexroth AG
Communication
DOK-RCON03-EFC-X610***-IT05-EN-P
271/389
