E9: Protection and error parameters
Code Name Setting range Default Min. Attri.
E9.00 Automatic error reset attempts
0...3
(0: Inactive)
0 – Stop
E9.01 Automatic error reset interval 0.1...60.0 s 10.0 0.1 Stop
E9.05 Last error type – – – Read
E9.06 Second last error type – – – Read
E9.07 Third last error type – – – Read
E9.10 Output frequency at last error – – 0.01 Read
E9.11 Setting frequency at last error – – 0.01 Read
E9.12 Output current at last error – – 0.1 Read
E9.13 Output voltage at last error – – 1 Read
E9.14 DC-bus voltage at last error – – 1 Read
E9.15 Power module temperature at last error – – 1 Read
E9.97 Last detailed error type 00000...FFFFF 0 – Read
E9.98 Second last detailed error type 00000...FFFFF 0 – Read
E9.99 Third last detailed error type 00000...FFFFF 0 – Read
Value range of E9.05...E9.07:
0: No error
1: OC-1, overcurrent at constant speed
2: OC-2, overcurrent during acceleration
3: OC-3, overcurrent during deceleration
4: OE-1, overvoltage at constant speed
5: OE-2, overvoltage during acceleration
6: OE-3, overvoltage during deceleration
7: OE-4, overvoltage during stop
8: UE-1, undervoltage during run
9: SC, surge current or short circuit
10: IPH.L, input phase loss
11: OPH.L, output phase loss
12: ESS-, soft start error
20: OL-1, converter overload
21: OH, converter over temperature
22: UH, converter under temperature
23: FF, fan failure
Bosch Rexroth AG
Appendix
EFC x610 Series
354/389
DOK-RCON03-EFC-X610***-IT05-EN-P
