6.2 Technical Data
6.2.1 Electric Data
Model
Motor power
[kW]
200 V / 240 V
Input current [A]
200 V / 240 V
Output current [A]
Output capacity
[kVA]
0K40 0.4 6.2 / 5.1 2.4 / 2.0 0.8
0K75 0.75 10.1 / 8.4 4.1 / 3.4 1.4
1K50 1.5 16.2 / 13.5 7.3 / 6.1 2.5
2K20 2.2 22.3 / 18.6 10.1 / 8.4 3.5
Tab. 6-1: 1P 200 VAC 0K40...2K20 electric data
Model
Motor power
[kW]
380 V / 480 V
Input current [A]
380 V / 480 V
Output current [A]
Output capacity
[kVA]
0K40 0.4 1.5 / 1.2 1.3 / 1.1 0.9
0K75 0.75 2.6 / 2.0 2.3 / 1.8 1.5
1K50 1.5 4.8 / 3.8 4.0 / 3.2 2.7
2K20 2.2 6.8 / 5.4 5.6 / 4.4 3.7
3K00 3.0 9.1 / 7.2 7.4 / 5.9 4.9
4K00 4.0 11.9 / 9.4 9.7 / 7.7 6.4
Tab. 6-2: 3P 400 VAC 0K40...4K00 electric data
Model
Motor power
HD [kW]
380 V / 480 V
Input current [A]
380 V / 480 V
Output current [A]
Output capacity
[kVA]
5K50 5.5 15.7 / 12.4 12.7 /10.0 8.3
7K50 7.5 21.0 / 16.7 16.8 / 13.3 11.1
11K0 11.0 28.0 / 22.2 24.3 / 19.2 16.0
15K0 15.0 37.8 / 29.9 32.4 / 25.6 21.3
18K5 18.5 45.8 / 36.3 39.2 / 31.0 25.8
22K0 22.0 52.7 / 41.7 45.0 / 36.0 29.7
30K0 30.0 56.8 / 44.9 60.8 / 48.1 40.0
37K0 37.0 69.6 / 55.1 73.7 / 58.3 48.5
45K0 45.0 86.0 / 68.0 89.0 / 71.0 58.6
55K0 55.0 105.0 / 83.0 108.0 / 86.0 71.3
75K0 75.0 140.0 / 111.0 147.0 / 116.0 96.6
90K0 90.0 167.0 / 133.0 176.0 / 139.0 115.7
Tab. 6-3: 3P 400 VAC 5K50...90K0, electric data, HD (heavy duty)
EFC x610 Series Bosch Rexroth AG
Frequency Converter Overview
DOK-RCON03-EFC-X610***-IT05-EN-P
23/389
