REXROTH EFC 3610 Series User Manual

7.2 Heat Dissipation
1P 200 VAC
Frame Model
Heat dissipation
[W] [BTU/h]
B 0K40 40 136
B 0K75 70 256
C 1K50 120 409
D 2K20 165 563
Tab. 7-1: 1P 200 VAC heat dissipation
3P 400 VAC
Frame Model
Heat dissipation
[W] [BTU/h]
B 0K40 20 68
B 0K75 37 126
C 1K50 75 256
C 2K20 99 338
D 3K00 135 461
D 4K00 180 614
E 5K50 210 714
E 7K50 255 867
F 11K0 320 1,088
F 15K0 435 1,479
G 18K5 530 1,802
G 22K0 640 2,176
H 30K0 745 2,533
H 37K0 874 2,972
I 45K0 1405 4794
I 55K0 1951 6658
J 75K0 2074 7076
J 90K0 2653 9051
Tab. 7-2: 3P 400 VAC heat dissipation
Bosch Rexroth AG
Frequency Converter Mounting
EFC x610 Series
32/389
DOK-RCON03-EFC-X610***-IT05-EN-P
