19.6.2 Installation
Terminal Definition
Connection Signal name Function
1 COM COM is the reference of +24 V
2 STO1+ Input channel 1
3 STO1- The reference of Input channel 1
4 STO2+ Input channel 2
5 STO2- The reference of Input channel 2
6 +24 V Power supply
Tab. 19-4: Terminal definition
Cable Definition
Cable Unit Min. Max.
Type 2*2 cables, low voltage, single shielded, twisted pair
Wire-end ferrule w/plastic collar (for STO terminal)
Cross-section
mm
2
1 1
AWG 17 17
Ferrule length mm 12 12
Stripped length mm 15 15
Wire-end ferrule w/o plastic collar (for STO terminal)
Cross-section
mm
2
1 1.5
AWG 17 16
Ferrule length mm 10 10
Stripped length mm 10 10
Tab. 19-5: Cable definition
EFC x610 Series Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-X610***-IT05-EN-P
379/389
