12.5.3 Direction Control
Direction control via operation panel
The actual direction is controlled by the configuration of parameter [U0.00] 'Di-
rection control by panel' and [E0.17] 'Direction control'.
Code Name Setting range Default Min. Attri.
U0.00
Direction control by
panel
0: Forward
1: Reverse
0 – Run
E0.17 Direction control
0: Forward / Reverse
1: Forward only
2: Reverse only
3: Swap default direction
0 – Stop
[E0.17] setting [U0.00] setting Actual direction
0 Forward / Reverse
Forward Forward
Reverse Reverse
1 Forward only
Forward Forward
Reverse Converter stop and show error code 'dir1'
2 Reverse only
Forward Converter stop and show error code 'dir2'
Reverse Reverse
3 Swap default direction
Forward Reverse
Reverse Forward
Tab. 12-9: Direction configuration
For error codes 'dir1', 'dir2' concerning direction control, see chap-
ter 13.4 "Error Code" on page 242.
Reverse running frequency
Code
Name Setting range Default Min. Attri.
E0.11 Reverse running frequency 0.00...[E0.09] Hz 0.00 0.01 Run
When the converter is running in reverse direction, the setting frequency will be
defined by E0.11.
This reverse running frequency is
ONLY active when converter is NOT
running in multi-speed, simple PLC, or PID control mode.
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
152/389
DOK-RCON03-EFC-X610***-IT05-EN-P
