12.9.7 PID Engineering Value Display
This function is used to display an engineering value which is convenient for the
application engineering with scaling the output value, follow the equations be-
low:
● User-defined setting speed:
[d0.04] = [d0.02] x [E5.02]
● User-defined output speed:
[d0.05] = [d0.00] x [E5.02]
Code Name Setting range Default Min. Attri.
E5.02 User-defined speed scaling factor 0.01...100.00 1.00 0.01 Run
d0.01 Actual speed – – 1 rpm Read
d0.03 Setting speed – – 1 rpm Read
d0.04 User-defined setting speed – – 0.1 Read
d0.05 User-defined output speed – – 0.1 Read
d0.70 PID reference engineering value – – 0.1 Read
d0.71 PID feedback engineering value – – 0.1 Read
[d0.70] = [E4.02] x [PID reference]
[d0.71] = [E4.02] x [PID feedback]
EFC x610 Series Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
193/389
