14.4.7 Communication parameter configuration
Communication related parameter settings
Parameter Name Parameter settings
E0.00 First frequency setting source 20: Communication
E0.01 First run command source 2: Communication
E0.02 Second frequency setting source 20: Communication
E0.03 Second run command source 2: Communication
E8.00 Communication protocol 1: Extension card
E8.03
Communication process data loss be-
havior
Depends on parameter setting
①
H1.00 PROFIBUS local address
H1.01 Present baud rate
(Read only)
H1.02 Present telegram type
H1.10 Output PZD 1
Depends on parameter setting
①
H1.11 Output PZD 2
H1.12 Output PZD 3
H1.13 Output PZD 4
H1.14 Output PZD 5
H1.15 Output PZD 6
H1.16 Output PZD 7
H1.17 Output PZD 8
H1.18 Output PZD 9
H1.19 Output PZD 10
H1.30 Input PZD 1
H1.31 Input PZD 2
H1.32 Input PZD 3
H1.33 Input PZD 4
H1.34 Input PZD 5
H1.35 Input PZD 6
H1.36 Input PZD 7
H1.37 Input PZD 8
H1.38 Input PZD 9
H1.39 Input PZD 10
Tab. 14-39: PROFIBUS-DP communication parameters
①
: See chapter "H1: PROFIBUS card parameters" on page 357 for
details.
EFC x610 Series Bosch Rexroth AG
Communication
DOK-RCON03-EFC-X610***-IT05-EN-P
283/389
