Cable specification for USA / Canada
● ONLY USE copper wires of 75 ℃ or above according to UL 508C.
● It is recommended to use shielded cables to connect the motor.
● *: If additional labels available with the terminals of 0K40...7K50,
please refer to the torque data on labels.
EFC x610
Model
Fuse (Class J) Power cables PE Cable Torque / Screw
[A] [AWG] [AWG] [N·m / lb·in] (Mx)
0K40 10.0 14 8 1.00* / 9.0 (M3)
0K75 15.0 14 8 1.00* / 9.0 (M3)
1K50 25.0 10 8 1.00* / 9.0 (M3)
2K20 30.0 10 8 1.00* / 9.0 (M3)
Tab. 8-3: 1P 200 VAC fuse and cable dimensions for USA / Canada
EFC x610
Model
Fuse (Class J) Power cables PE Cable Torque / Screw
[A] [AWG] [AWG] [N·m / lb·in] (Mx)
0K40 6.0 14 8 1.00* / 9.0 (M3)
0K75 10.0 14 8 1.00* / 9.0 (M3)
1K50 10.0 14 8 1.00* / 9.0 (M3)
2K20 15.0 14 8 1.00* / 9.0 (M3)
3K00 20.0 12 8 1.00* / 9.0 (M3)
4K00 20.0 12 8 1.00* / 9.0 (M3)
5K50 30.0 10 8 1.20* / 10.5 (M4)
7K50 40.0 8 8 1.20* / 10.5 (M4)
11K0 50.0 8 8 1.76 / 15.6 (M4)
15K0 60.0 6 6 1.76 / 15.6 (M4)
18K5 80.0 4 6 3.73 / 33.0 (M5)
22K0 100.0 2 4 3.73 / 33.0 (M5)
30K0 100.0 2 4 3.80 / 33.6 (M6)
37K0 125.0 1 3 3.80 / 33.6 (M6)
45K0 150.0 1 / 0 1 31.1 / 275.0 (5/16 in)
55K0 175.0 2 / 0 1 / 0 31.1 / 275.0 (5/16 in)
75K0 225.0 4 / 0 3 / 0 31.1 / 275.0 (5/16 in)
90K0 250.0 250 kcmil 3 / 0 31.1 / 275.0 (5/16 in)
Tab. 8-4: 3P 400 VAC fuse and cable dimensions for USA / Canada
Bosch Rexroth AG
Frequency Converter Wiring
EFC x610 Series
44/389
DOK-RCON03-EFC-X610***-IT05-EN-P
