REXROTH EFC 3610 Series User Manual

EFC x610
Model
Fuse (gG)
Power cables installation mode
PE Cable Torque / Screw
B1 B2 E
[A]
[mm
2
] [mm
2
] [mm
2
] [mm
2
]
[N·m / lb·in] (Mx)
30K0 125.0 35.0 50.0 35.0 25.0 3.80 / 33.6 (M6)
37K0 125.0 35.0 50.0 35.0 35.0 3.80 / 33.6 (M6)
45K0 160.0 50.0 70.0 50.0 35.0
31.1 / 275.0
(5/16 in)
55K0 200.0 70.0 95.0 70.0 50.0
31.1 / 275.0
(5/16 in)
75K0 250.0 120.0 150.0 95.0 95.0
31.1 / 275.0
(5/16 in)
90K0 250.0 120.0 150.0 95.0 95.0
31.1 / 275.0
(5/16 in)
Tab. 8-2: 3P 400 VAC fuse and cable dimensions for international without USA / Canada
EFC x610 Series Bosch Rexroth AG
Frequency Converter Wiring
DOK-RCON03-EFC-X610***-IT05-EN-P
43/389
