Slip compensation factor configuration
This function is used to compensate [C1.12] 'Motor rated slip compensation' ac-
cording to the actual applications in V/f control.
Code Name Setting range Default Min. Attri.
C2.07 Slip compensation factor 0…200 % 0 1 Run
● 0 %: No slip compensation
The slip compensation function is deactivated.
● 1...100 %: Full slip compensation
Example: [C1.12] = 2.50 Hz, [C2.07] = 100 %
The actual slip compensation is 2.50 Hz x 100 % = 2.50 Hz.
● 101...200 %: Over slip compensation
Example: [C1.12] = 2.50 Hz, [C2.07] = 200 %
The actual slip compensation is 2.50 Hz x 200 % = 5.00 Hz.
EFC x610 Series Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
219/389
