REXROTH EFC 3610 Series User Manual

15.8 Plug-in Connector for Control Section
For details on plug-in connector FEAE05.1-B2-NNNN, see fig. 8-9 "Control circuit
terminals" on page 54.
15.9 External EMC Filter
15.9.1 External EMC Filter Type
EFC x610 model External EMC filter type
0K40-1P2
FCAF01.1A-A050-E-0010-N-03-NNNN (0010-N-03)
0K75-1P2
1K50-1P2 FCAF01.1A-A050-E-0020-N-03-NNNN (0020-N-03)
2K20-1P2 FCAF01.1A-A050-E-0025-N-03-NNNN (0025-N-03)
0K40-3P4
FCAF01.1A-A050-E-0025-A-05-NNNN (0025-A-05)
0K75-3P4
1K50-3P4
2K20-3P4
3K00-3P4
4K00-3P4
5K50-3P4
FCAF01.1A-A050-E-0036-A-05-NNNN (0036-A-05)
7K50-3P4
11K0-3P4
FCAF01.1A-A050-E-0050-A-05-NNNN (0050-A-05)
15K0-3P4
18K5-3P4 FCAF01.1A-A050-E-0066-A-05-NNNN (0066-A-05)
22K0-3P4 FCAF01.1A-A050-E-0090-A-05-NNNN (0090-A-05)
30K0-3P4
FCAF01.1A-A100-E-0120-A-05-NNNN (0120-A-05)
37K0-3P4
45K0-3P4
FCAF01.1A-A100-E-0250-N-05-NNNN (0250-N-05)
55K0-3P4
75K0-3P4
FCAF01.1A-A100-E-0320-N-05-NNNN (0320-N-05)
90K0-3P4
Tab. 15-4: External EMC filter type
●
Only mount the EMC filter FCAF vertically. Keep at least 80 mm
above the top and below the bottom of the EMC filter free from
mounted parts.
● For EMC performance with the external EMC filter, see chapter
6.2.3 "Maximum Length of Motor Cables" on page 30.
Bosch Rexroth AG
Accessories
EFC x610 Series
298/389
DOK-RCON03-EFC-X610***-IT05-EN-P
