Additional status register (0x7FA1)
Additional status register is the extension of main status register(7FA0H), it
stores other status information of frequency converter. This register is read-only.
The definition of each bit is shown in the table below:
bit Value Description
15...4 – Reserved
3
1 DC braking
0 Not DC braking
2
1 Coasting to stop
0 Not coasting
1
1 Speed tracing
0 Not tracing
0
1 Not 0 speed
0 0 speed
Tab. 14-26: Additional status register (0x7FA1)
