REXROTH EFC 3610 Series User Manual

Set digital / analog output terminals
Code Name Setting range Default Min. Attri.
H8.20 EDO output setting
0...20
1 – Stop
H8.21
Extended relay output
selection
1 – Stop
H8.25 EAO output mode 0: 0…10 V; 1: 0...20 mA 0 – Run
H8.26 EAO output selection
0: Running frequency
1: Set frequency
2: Output current
4: Output voltage
5: Output power
6: AI1 analog input
7: AI2 analog input
8: EAI analog input
11: Motor temperature sensor power
0 – Run
H8.27 EAO gain 0.00...10.00 1.00 0.01 Run
Perform the self-test function
Code Name Setting range Default Min. Attri.
H8.87
I/O card output channel
diagnosis
0: Inactive
1: EAO diagnosis
2: EDO diagnosis
3: ERO diagnosis
4: All output diagnosis
0 – Stop
● 0: Inactive
The test is complete. All outputs are restored to default settings.
● 1: EAO diagnosis. The analog output of I/O card outputs 10 V.
● 2: EDO diagnosis. The open collector output of I/O card outputs 10 V.
● 3: ERO diagnosis. The relay output of I/O card is closed.
● 4: All output diagnosis. EAO, ERO, EDO are all tested with the above methods.
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
120/389
DOK-RCON03-EFC-X610***-IT05-EN-P
