15.10.3 Brake Resistor Type for Braking Ratio of 20 %
1P 200 VAC
Converter model
Brake resistor
Type Specification Number
0K40 FCAR01.1W0100-N400R0-B-03-NNNN 400 Ω / 100 W 1
0K75 FCAR01.1W0200-N190R0-B-03-NNNN 190 Ω / 200 W 1
1K50 FCAR01.1W0400-N095R0-B-03-NNNN 95 Ω / 400 W 1
2K20 FCAR01.1W0500-N065R0-B-03-NNNN 65 Ω / 500 W 1
Tab. 15-9: 1P 200 VAC with braking ratio of 20 %
3P 400 VAC
Converter model
Brake resistor
Type Specification Number
0K40 FCAR01.1W0150-N750R0-B-05-NNNN 750 Ω / 150 W 1
0K75 FCAR01.1W0150-N750R0-B-05-NNNN 750 Ω / 150 W 1
1K50 FCAR01.1W0520-N350R0-A-05-NNNN 350 Ω / 520 W 1
2K20 FCAR01.1W0520-N230R0-A-05-NNNN 230 Ω / 520 W 1
3K00 FCAR01.1W0780-N140R0-A-05-NNNN 140 Ω / 780 W 1
4K00 FCAR01.1W0780-N140R0-A-05-NNNN 140 Ω / 780 W 1
5K50 FCAR01.1W1K56-N070R0-A-05-NNNN 70 Ω / 1,560 W 1
7K50 FCAR01.1W1K56-N070R0-A-05-NNNN 70 Ω / 1,560 W 1
11K0 FCAR01.1W02K0-N047R0-A-05-NNNN 47 Ω / 2,000 W 1
15K0 FCAR01.1W03K0-N034R0-A-05-NNNN 34 Ω / 3,000 W 1
18K5 FCAR01.1W10K0-N028R0-A-05-NNNN 28 Ω / 10,000 W 1
22K0 FCAR01.1W10K0-N028R0-A-05-NNNN 28 Ω / 10,000 W 1
Tab. 15-10: 3P 400 VAC with braking ratio of 20 %
