Perform the self-test function
Code Name Setting range Default Min. Attri.
H9.97 Relay card output channel diagnosis
0: Inactive
1: Relay1 diagnosis
2: Relay2 diagnosis
3: Relay3 diagnosis
4: Relay4 diagnosis
5: All output diagnosis
0 Stop
0: Inactive
All relays are restored to default settings.
1: Relay1 diagnosis
Relay1 is closed.
2: Relay2 diagnosis
Relay2 is closed.
3: Relay3 diagnosis
Relay3 is closed.
4: Relay4 diagnosis
Relay4 is closed.
5: All output diagnosis
All relays are closed.
Relay card output status is monitored by parameter d0.63 'Relay
card output'.
EFC x610 Series Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
123/389
