12.5.2 Run Command Source
First and second run command source configuration
Code Name Setting range Default Min. Attri.
E0.01 First run command source 0...2 0 – Stop
E0.03 Second run command source 0...2 1 – Stop
● 0: Operating panel
Control the frequency converter for run and stop with <Run>, <Stop> buttons
on the operating panel.
Control the running direction by setting parameters U0.00 'Direction control
by panel' and E0.17 'Direction control'.
● 1: Multi-function digital input
Control the frequency converter for run, stop and running direction by setting
digital inputs.
● 2: Communication
Control the frequency converter for run, stop and running direction with Mod-
bus communication protocol.
Switch between first and second run command source
Code Name Setting range Default Min. Attri.
E1.00 X1 input
31: Second run command source activation
35 – Stop
E1.01 X2 input 36 – Stop
E1.02 X3 input 0 – Stop
E1.03 X4 input 0 – Stop
E1.04 X5 input 0 – Stop
H8.00 EX1 input 0 – Stop
H8.01 EX2 input 0 – Stop
H8.02 EX3 input 0 – Stop
H8.03 EX4 input 0 – Stop
If status of the selected terminal is changed when converter is running, the run
command source will be switched and the converter will freewheel to stop. The
active / inactive of digital input is triggered by voltage level.
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
150/389
DOK-RCON03-EFC-X610***-IT05-EN-P
