6.1.9 Conditions
Rated ambient temperature -10...45 ℃
Derating / ambient temperature 1.5 % / 1 °C (45...55 °C)
Rated storage temperature -20...60 ℃
Rated altitude ≤ 1,000 m
Derating / altitude 1 % / 100 m (1,000...4,000 m)
Relative humidity ≤ 90 % RH (No condensation)
Degrees of protection IP 20 (Control cabinet mounting)
Degrees of pollution 2 (EN 50178)
Vibration
10 Hz ≤ f ≤ 57 Hz amplitude: 0.075 mm
57 Hz < f ≤ 150 Hz acceleration: 1 g
Mounting mode
Wall mounting
DIN rail mounting (For 0K40...7K50 models)
Cooling type
Natural cooling (≤ 0K75)
Enforced air cooling (≥ 1K50)
Certification
CE (applicable to 0K40...90K0)
cUL (applicable to 0K40...90K0)
EAC (applicable to 0K40...90K0)
RCM (applicable to 0K40...90K0)
Bosch Rexroth AG
Frequency Converter Overview
EFC x610 Series
22/389
DOK-RCON03-EFC-X610***-IT05-EN-P
