7.3 Air Flow of Fans
1P 200 VAC
Frame Model
Fan for heat sink Fan for internal components
[CFM]
[m
3
/min]
[CFM]
[m
3
/min]
B 0K40 – – – –
B 0K75 – – – –
C 1K50 19.20 0.54 – –
D 2K20 19.20 0.54 – –
Tab. 7-3: 1P 200 VAC air flow of fans
3P 400 VAC
Frame Model
Fan for heat sink Fan for internal components
[CFM]
[m
3
/min]
[CFM]
[m
3
/min]
B 0K40 – – – –
B 0K75 – – – –
C 1K50 19.20 0.54 – –
C 2K20 19.20 0.54 – –
D 3K00 19.20 0.54 – –
D 4K00 19.20 0.54 – –
E 5K50 40.00 1.13 32.17 0.91
E 7K50 40.00 1.13 32.17 0.91
F 11K0 56.50 1.60 34.90 0.99
F 15K0 56.50 1.60 34.90 0.99
G 18K5 40.00 1.13 34.90 0.99
G 22K0 49.20 1.39 47.60 1.35
H 30K0 120.20 3.40 – –
H 37K0 120.20 3.40 – –
I 45K0 215.74 6.11 – –
I 55K0 215.74 6.11 – –
J 75K0 215.74 6.11 – –
J 90K0 215.74 6.11 – –
Tab. 7-4: 3P 400 VAC air flow of fans
EFC x610 Series
Bosch Rexroth AG
Frequency Converter Mounting
DOK-RCON03-EFC-X610***-IT05-EN-P
33/389
