Adjust the setting frequency by multi-speed function
Multi-speed function offers flexible, switchable 16 independent stages of setting
frequency. The rotation direction of each stage depends on both the 'Stage ac-
tion' and the 'Run command source', see the table below:
Frequency source Run command source Rotation direction Acc. / Dec. time
Multi-speed
Operating panel
[E3.60], [E3.62], [E3.64], [E3.66]
[E3.68], [E3.70], [E3.72], [E3.74]
[E3.76], [E3.78], [E3.80], [E3.82]
[E3.84], [E3.86], [E3.88], [E3.90]
[E0.26] / [E0.27]
[E3.10] / [E3.11]
[E3.12] / [E3.13]
[E3.14] / [E3.15]
[E3.16] / [E3.17]
[E3.18] / [E3.19]
[E3.20] / [E3.21]
[E3.22] / [E3.23]
External terminals
8 or less stages: 2-wire control
9 or more stages: parameters
Communication Set by communication
Tab. 12-4: Setting frequency and multi-speed settings
To configure the multi-speed settings, take the following steps:
Step 1: Activate multi-speed function
Code Name Setting range Default Min. Attri.
E0.00 First frequency setting source
21: Multi-speed settings
0 – Stop
E0.02 Second frequency setting source 2 – Stop
Step 2: Select any 3 digital inputs and define functions accordingly
Assign functions to digital inputs properly when 'Acceleration / deceleration
time activation' and '2-wire / 3-wire running control' are also necessary defined
via digital inputs.
Code
Name Setting range Default Min. Attri.
E1.00 X1 input
1: Multi-speed control input 1
2: Multi-speed control input 2
3: Multi-speed control input 3
4: Multi-speed control input 4
35 – Stop
E1.01 X2 input 36 – Stop
E1.02 X3 input 0 – Stop
E1.03 X4 input 0 – Stop
E1.04 X5 input 0 – Stop
H8.00 EX1 input 0 – Stop
H8.01 EX2 input 0 – Stop
H8.02 EX3 input 0 – Stop
H8.03 EX4 input 0 – Stop
Step 3: Configure the setting frequency for each stage
If the setting frequency of next stage is lower than that of the current stage, it
will decelerate to the next stage with the deceleration time of the current stage;
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
136/389
DOK-RCON03-EFC-X610***-IT05-EN-P
