6.2.3 Maximum Length of Motor Cables
Model Configuration
Maximum length of motor cables
C3 [m] C1 [m]
0K40…4K00
EFC x610 (internal EMC filter) 15 –
EFC x610 (internal EMC filter) +
External EMC filter
50 –
EFC x610 (Internal EMC filter) +
External EMC filter +
Output choke
75 10
5K50…22K0
EFC x610 (internal EMC filter) 30 –
EFC x610 (internal EMC filter) +
External EMC filter
50 –
EFC x610 (internal EMC filter) +
External EMC filter +
Output choke
100 10
30K0…37K0
EFC x610 (internal EMC filter) 50 –
EFC x610 (internal EMC filter) +
External EMC filter
100 –
EFC x610 (internal EMC filter) +
External EMC filter +
Output choke
150 30
45K0…90K0
EFC x610 (internal EMC filter) 50 –
EFC x610 (internal EMC filter) +
External EMC filter
100 –
EFC x610 (internal EMC filter) +
External EMC filter +
Output choke
150 –
Tab. 6-5: Maximum length of motor cables
1.
ONLY CONDUCTED EMISSION can be guaranteed for C1.
2. SHIELDED MOTOR CABLES are used in test.
