12.7.2 Frequency Arrival
This function is used to detect the difference between the output frequency and
the setting frequency. When the difference is within the frequency detection
width, an indication signal will be generated for further engineering in the appli-
cation.
Code Name Setting range Default Min. Attri.
E2.01 DO1 output setting
4: Speed arrival
1 – Stop
E2.15 Relay 1 output selection 1 – Stop
H8.20 EDO output setting 1 – Stop
H8.21
Extended relay output selec-
tion
1 – Stop
H9.00
Extended relay 1 output se-
lection
0 – Stop
H9.01
Extended relay 2 output se-
lection
0 – Stop
H9.02
Extended relay 3 output se-
lection
0 – Stop
H9.03
Extended relay 4 output se-
lection
0 – Stop
E2.70 Frequency detection width 0.00...400.00 Hz 2.50 0.01 Run
The 'Speed arrival' signal is active on the selected output terminal when the dif-
ference between the 'Output frequency' and the 'Setting frequency' is within the
range set by parameter E2.70 'Frequency detection width':
EFC x610 Series
Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
175/389
