12.2 Input and Output Terminals Configuration
12.2.1 Digital Input Configuration
5 multi-function digital inputs are available with PNP and NPN wiring.
Code Name Setting range Default Min. Attri.
E1.00 X1 input
0...46
35 – Stop
E1.01 X2 input 36 – Stop
E1.02 X3 input 0 – Stop
E1.03 X4 input 0 – Stop
E1.04 X5 input 0...47 0 – Stop
● 0: Inactive
● 1: Multi-speed control input 1
● 2: Multi-speed control input 2
● 3: Multi-speed control input 3
● 4: Multi-speed control input 4
16 multi-speeds are available by combination of 4 terminals, see chapter "Adjust
the setting frequency by multi-speed function" on page 136.
● 10: Acceleration / deceleration time 1 activation
●
11: Acceleration / deceleration time 2 activation
● 12: Acceleration / deceleration time 3 activation
Used to switch between 8 groups of acceleration / deceleration time, see chap-
ter 12.4.3 "Acceleration and Deceleration Configuration" on page 142.
● 15: Freewheeling stop activation
'Freewheeling stop activation' generates a stop command and forces the fre-
quency converter to freewheel to stop regardless of the stopping mode con-
figured by E0.50.
● 16: Stop DC-braking activation
This function is used when stopping mode is set with [E0.50] = '0: Decelerat-
ing stop'.
See chapter 12.5.5 "Stop Behavior Setting" on page 159
● 20: Frequency Up command
● 21: Frequency Down command
● 22: Up / Down command reset
Used to change the output frequency, see chapter "Adjust the setting frequency
by digital input Up / Down command" on page 134.
● 23: Torque / speed control switch
● 25: 3-wire control
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
106/389
DOK-RCON03-EFC-X610***-IT05-EN-P
