Used for the 3-wire control mode, see chapter 12.6.3 "2-wire / 3-wire Control
(Forward / stop, reverse / stop)" on page 168.
● 26: Simple PLC stop
● 27: Simple PLC pause
Used for the simple PLC to stop and pause a PLC cycle, see chapter 12.8.4
"Stop and Pause Simple PLC Control" on page 183.
● 30: Second frequency setting source activation
Used for switching to the second frequency setting source, see chapter "Fre-
quency setting source switching" on page 130.
● 31: Second run command source activation
Used for switching to the second run command source, see chapter "Switch
between first and second run command source" on page 150.
● 32: Error signal N.O. contact input
● 33: Error signal N.C. contact input
Used for receive error signal from external sources, see chapter "Reaction to Ex-
ternal Error Signals" on page 204.
● 34: Error reset
Used for error reset operation, see chapter 13.5 "Error Handling" on page
251.
● 35: Forward running (FWD)
● 36: Reverse running (REV)
Used for Run / Stop command control, see chapter 12.5 "Run- / Stop- / Direc-
tion Command Source" on page 149.
● 37: Forward jog
● 38: Reverse jog
See chapter 12.6.2 "Jog Function" on page 166.
● 39: Counter input
● 40: Counter reset
See chapter 12.7.1 "Counter Function" on page 172.
● 41: PID deactivation
See chapter 12.9 "PID Control" on page 186.
● 46: User parameter set selection
● 47: Pulse input mode activation (ONLY for X5 input)
See chapter 12.2.2 " X5 Pulse Input Configuration" on page 108.
Digital input status is monitored by parameter d0.40 'Digital input 1'.
EFC x610 Series Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
107/389
